HAND-BUILT: Motorcycle Frames, Part 1 of 5

A look at how to approach a frame build and why you’d want to tackle a build in the first place.

welding a motorcycle frame

Jeff Palhegy reminds us that when welding a frame together, “You don’t just weld one side up and then forget about the other side. You weld a little here, a little there, a little here, and a little there, otherwise you can imagine the frame is going to start to pull one way or another.”

Jeff Allen

BUILDER: Jeff Palhegyi of Jeff Palhegyi Design

Nothing worth doing is easy. This is true in life and in custom frame fabrication, a part of the motorcycle-building process that stems from a budding desire (if not necessity) to make a bike uniquely yours. What, after all, could be more rewarding than rolling down the road on something you welded together with your own two hands?

Those hands won’t need to have been brazed by countless hours spent in a metal shop either. Sure, experience with a TIG welder and grinder will go a long way in making the job go more seamlessly, but trained hands are no more a mandate than a commitment to planning and willingness to learn something new.

motorcycle frame build in-progress

The challenge of keeping a frame straight despite the welding process wanting to contort the metals and your sanity all at once is part of what makes frame building such a unique and exciting part of the motorcycle building process.

Jeff Allen

Jeff Palhegyi of Jeff Palhegyi Design, a custom fabrication shop that works with Yamaha to create special models such as the DT-07 flat-track bike, drives that point home, saying that, “The work leading up to fitting the first tubes is actually three times as difficult as actually assembling the pieces. You need to do the research and know exactly the parameters you want—the wheelbase, the head angle, seat height, engine dimensions, all of that.”

There’s no industry standard, but generally speaking there are sets of numbers that work best for specific types of bikes, with Palhegyi adding that, “You’d be foolish to not look at what works and base what you’re doing around that.” Read books. Find articles on the web. Search everywhere and you will find the numbers you want.

close-up of welded motorcycle frame

Jeff Palhegyi of Jeff Palhegyi Design, a custom fabrication shop that works with Yamaha to create special models such as the tuning fork brand’s DT-07 flat-track bike, says that the time leading up to actually welding the frame together is the most difficult, because of the amount of research you’ll need to do in order to figure out exactly what parameters you want for things like wheelbase and rake.

Jeff Allen

Once you have the necessary information and know what pieces will go where, you’ll need to build a fixture, which will enable you to build your frame square and straight. While guys like Palhegyi use something that wouldn’t budge if you smacked it with a wrecking ball, know that yours will need to at least center on a flat table and components that are solid enough they won’t allow for movement in the welding process. Of course, “The stronger and more rigid the fixture is, the better the parts are going to be after the welding process,” Palhegyi explains.

close-up of motorcycle frame weld

Experience with a TIG welder and grinder will go a long way in helping you make your very own frame, but trained hands are no more a mandate than a willingness to learn something new. Even if it doesn’t come out looking as beautiful as this piece from Jeff Palhegyi Design, you can take pride in knowing you did it yourself.

Jeff Allen

Movement is the enemy in frame building but also something that’s hard to avoid, as the heat generated from welding causes the metals (regardless of which kind) to shrink and pull. “You never know by how much,” Palhegyi suggests, but, “Whether it’s eighteen-thousandths or twenty-thousandths, you have to know that it’s going to move, and you have to plan for that.” Regarding materials, remember also that chrome-moly will be stronger and can be made thinner, so eventually it ends up being lighter, while steel is less resilient and heavier but also cheaper.

close-up of motorcycle frame weld

You never know how much the frame’s pieces will shrink and pull as you start to weld, suggests Palhegyi but, “Whether it’s eighteen-thousandths or twenty-thousandths, you have to know that it’s going to move, and you have to plan for that.

Jeff Allen

Don’t let the idea of shrinking metals intimidate you, as there are actually ways to limit the effects, one being to build subassemblies. These assemblies, welded together on a separate fixture, will pull and shrink as their individual pieces are fused together but in the end have a deter­mined shape, meaning it won’t contort as you attach it to the other parts of the frame and throw things off even more.

Also, you should tack weld pieces together and then weld the components up on either side evenly (similar to how you’d tighten all bolts evenly on an engine cover). “You weld a little here, a little there, and a little there, otherwise the frame is going to start to pull one way or another,” Palhegyi says.

Sure, things can go askew. Or plans will change. But remember, nothing worth doing is easy. And the payoff is in the gratification you get while rolling down the road on something you welded together yourself.

welding a motorcycle frame

One of the keys to keeping a frame straight as it’s welded together is to build sub-assemblies on a fixture of their own.

Jeff Allen
